PP Raffia Extruder

Screw and barrel are made of nitride steel 38CrMoAl with special hardening, has good corrosion resistance and wear resistance, longer life.
AC Inverter & Motor can synchronize the entire extruder.
Latest technology used for force the melt into the die very effectively.

Online Inquiry Contact Us

Product Details

Technical data:

Item	NY-SLJ-70	NY-SLJ-80	NY-SLJ-90
T-die Width	600mm	800mm	1000mm
Screw Diameter	70mm	80mm	90mm
Fiber Type	PP/PE/HDPE Film, Split Film, Raffia Twine and so on
Ratio of L/D	33	33	33
Rotation Speed of Screw	20-90r/min	20-90r/min	20-90r/min
Drawing Ratio	4-10	4-10	4-10
Cooling Mode	Water Cooling	Water Cooling	Water Cooling
Power Consumption	100KW/60KW	130KW/80KW	150KW/100KW
Max Output capacity	1200KG/24H	2000KG/24H	3000KG/24H
Machine Weight	13 Tons	15 Tons	18 Tons
Machine Dimension(LWH)	2522m	262.22m	272.22m

Performance & Advantages:

Screw and barrel are made of nitride steel 38CrMoAl with special hardening, has good corrosion resistance and wear resistance, longer life.
AC Inverter & Motor can synchronize the entire extruder.
Latest technology used for force the melt into the die very effectively.
Take up small area.
Easy operation.
High output capacity.
